Serially-produced frame house total area of 56 m² with an open terrace.
The house is built on a site according to frame technology using preprepared elements. The lightweight structure is erected on reinforced concrete foundation. The house is heat-insulated for living in winter.
The house is built on a site according to frame technology using preprepared elements. The lightweight structure is erected on reinforced concrete foundation. The house is heat-insulated for living in winter.
The space of the house is used with maximum efficiency — it contains exactly as much space as is necessary for a comfortable stay.
With a small internal area, the house contains two bedrooms with built-in wardrobes, a bathroom with a bath, a spacious entrance hall and a kitchen-living room.
The terrace can have any shape and size.
With a small internal area, the house contains two bedrooms with built-in wardrobes, a bathroom with a bath, a spacious entrance hall and a kitchen-living room.
The terrace can have any shape and size.
DELO HOUSE 2
PROST
Shelving with five shelves
375 €
Shelving with five shelves
375 €
The project allows two bedrooms to be combined into one and provide more storage space.
The layout can be mirrored in any direction, and the windows can be positioned depending on the cardinal points, the desired view and the access way.
The house has a simple, easy-to-build and reliable structure.
During construction, only high-quality, environmentally friendly materials are used. The house is designed taking into account the standard sizes of materials and almost no wasteleft during its construction. This optimizes its cost and saves natural resources.
The layout can be mirrored in any direction, and the windows can be positioned depending on the cardinal points, the desired view and the access way.
The house has a simple, easy-to-build and reliable structure.
During construction, only high-quality, environmentally friendly materials are used. The house is designed taking into account the standard sizes of materials and almost no wasteleft during its construction. This optimizes its cost and saves natural resources.
24.25 m²
3.45 m²
8.60 m²
8.60 m²
6.85 m²
4.45 m²
10.5 m²
56.2 m²
80.6 m²
13 м х 6.2 м х 4.4 m
3.45 m²
8.60 m²
8.60 m²
6.85 m²
4.45 m²
10.5 m²
56.2 m²
80.6 m²
13 м х 6.2 м х 4.4 m
1. Kitchen-living room
2.Bathroom
3. Bedroom
4. Bedroom
5. Hall
6. Entrance hall
7. Terrace
Usable floor area:
Built-up area:
Dimensions (L х W х H):
2.Bathroom
3. Bedroom
4. Bedroom
5. Hall
6. Entrance hall
7. Terrace
Usable floor area:
Built-up area:
Dimensions (L х W х H):
1
2
3
4
5
6
7
6.2 m
13 m
4.4 m
2.85 m
0
DELO HOUSE 2
Frame house total area of 56 m² with an open terrace.
The house is built on a site according to frame technology using preprepared elements. The lightweight structure is erected on reinforced concrete foundation. The house is heat-insulated for living in winter.
The house is built on a site according to frame technology using preprepared elements. The lightweight structure is erected on reinforced concrete foundation. The house is heat-insulated for living in winter.
The space of the house is used with maximum efficiency — it contains exactly as much space as is necessary for a comfortable stay.
With a small internal area, the house contains two bedrooms with built-in wardrobes, a bathroom with a bath, a spacious entrance hall and a kitchen-living room.
The terrace can have any shape and size.
With a small internal area, the house contains two bedrooms with built-in wardrobes, a bathroom with a bath, a spacious entrance hall and a kitchen-living room.
The terrace can have any shape and size.
The project allows two bedrooms to be combined into one and provide more storage space.
The layout can be mirrored in any direction, and the windows can be positioned depending on the cardinal points, the desired view and the access way.
The house has a simple, easy-to-build and reliable structure.
During construction, only high-quality, environmentally friendly materials are used. The house is designed taking into account the standard sizes of materials and almost no wasteleft during its construction. This optimizes its cost and saves natural resources.
The layout can be mirrored in any direction, and the windows can be positioned depending on the cardinal points, the desired view and the access way.
The house has a simple, easy-to-build and reliable structure.
During construction, only high-quality, environmentally friendly materials are used. The house is designed taking into account the standard sizes of materials and almost no wasteleft during its construction. This optimizes its cost and saves natural resources.
1. Kitchen-living room: 24.25 m²
2. Bathroom: 8.60 m²
3. Bedroom: 8.60 m²
4. Bedroom: 8.60 m²
5. Hall: 6.85 m²
6. Entrance hall: 4.45 m²
7. Terrace: 10.5 m²
Usable floor area: 56.2 m²
Built-up area: 80.6 m²
Dimensions (L х W х H): 13 м х 6.2 м х 4.4 m
2. Bathroom: 8.60 m²
3. Bedroom: 8.60 m²
4. Bedroom: 8.60 m²
5. Hall: 6.85 m²
6. Entrance hall: 4.45 m²
7. Terrace: 10.5 m²
Usable floor area: 56.2 m²
Built-up area: 80.6 m²
Dimensions (L х W х H): 13 м х 6.2 м х 4.4 m
House price
House with finishing | Built-up area | 80.6 m² | |
| Usable floor area | 56.2 m² | ||
| Dimensions (LхWхH) | 13 m х 6.2 m х 4.4 m | ||
Frame | External walls, partitions | Planed kiln-dried board 196х46 mm | ≈ 11 mln ₽ |
| Floor beams | Planed kiln-dried board 196х46 mm | ||
| Rafters | Planed kiln-dried board 196х46 mm | ||
| Heat insulation | Rockwool Light Batts stone wool (or analogue from other manufacturers) walls -200 mm, ceiling - 200 mm; MDVP Beltermo 35 mm | ||
| Noise insulation of interior walls | Rockwool Light Batts stone wool 100 mm, plywood 10+10 mm | ||
| Wind and vapor barrier | Delta-Dawi GP film, MDM Ventia Bronze membrane, Delta Multi-Band M60 tape, MDVP Beltermo 35 mm | ||
Outside finishing | Roof | Corrugated sheet metal C-21 0.5 mm, corner elements, Grand Line gutter system | |
| Walls | Larch deck board 120х28 mm Floor lags: planed kiln-dried board 146х46 mm, screw piles | ||
| Entrance door | Thermal insulated door Alutech Аlt W72 | ||
Interior finishing | Walls and ceiling | Cedar planken, oil/paint, gypsum board, ceramic granite | |
| Floor | Terazzo tile 28 mm | ||
| Doors | Concealed installation doors (reinforced with HDF/particleboard ribs, pine wood core, MDF outer panel, and ABS edging) | ||
Glass fixing | Facade windows | Alutech aluminum double-glazed energy-saving windows with thermal break, impact-resistant glass with protection class A1 (P2A) | |
Lighting | Interior lighting | Surface mounted LED luminaires | |
Utility system | Water supply and sewage | Water supply (16x2.0 mm multilayer pipes, AlcaPlast shower drains, Geberit installation system for toilets), 200 L Stout indirect water heater, water supply unit with a bypass for water purification | |
| Electrical | Concealed wiring, built-in electrical panel, switches, and sockets. The house is equipped with separate circuit breakers (for outlets and lighting in each room, and separate ones for high-power appliances in the kitchen and boiler room). Residual current devices (RCDs) are installed in wet rooms for electrical safety. If necessary, a transfer switch for connection to an autonomous generator is installed | ||
| Ventilation | Healthbox 3.0 is a smart ventilation system that independently determines in which room ventilation needs to be increased or decreased based on real air quality indicators, including CO2 levels, humidity, odors (VOC), time of day, and the number of occupants | ||
| Heating | A water-based underfloor heating system with smartphone app control, featuring insulated edge zones along all windows and entryways. A 9 kW Protherm electric boiler with 9 power stages, pump, tank, and safety group. An Omnigena Omega 25/6 130 mm circulation pump with frequency control. MVI stainless steel manifold groups. Thermostatic heads TSG-VPS-01. ZONT SMART 2.0 WI-FI heating controller, ZONT ML-740 room temperature sensors, Ebus ECO module, ZONT 590 radio module | ||
Production time | 3,5 months |
Prices are valid as of September 1, 2024 for Saint Petersburg and the Leningrad Oblast
The price does NOT include:
Furniture and plumbing | Kitchen and wardrobe | Chipboard Egger | ≈ 2 mln ₽ | |
| Refrigerator | ||||
| Washer | ||||
| Tap | ||||
| Stove | ||||
| Lavatory basin | ||||
| Sink | ||||
| Shower | ||||
| Washing machine | ||||
| Sofa | Delo | |||
| Tables | Delo, Kroogster and Yo models | |||
| Chairs | Delo, Tu and Yo models | |||
| Bed | Solid pine, water-based varnish | |||
| Matress | 160х200 cm | |||
| Blanket | 200х200 cm | |||
| Pillows | 50x70 cm | |||
| Linens | Delo Design | |||
| Tablware | Delo | |||
Foundation | Concrete slab (the cost of the foundation depends on the location, the type of soil, the length of the piles, the need to remove stones, etc. It is recommended to take a soil sample and conduct inspection) | ≈ 1.2 mln ₽ | ||
Wastewater treatment station | KITARI Black-5 / Eurobion 5 (for 2-5 people) | Erection: excavation, digging, submersion of the station, backfilling of the central heating station (ratio of cement to sand 1/4, 1/3) connection of electrics, (100 km from the pumping equipment, city) welding of branch piping, inspection and laying of pipes up to 10m, lead -into the house | ≈ 212 000 ₽ (in 100 km from the city) | |
| Eurobion 3 (for 3 people) | ≈ 200 000 ₽ | |||
Wood burning fireplace | 100 000 ₽ | |||
Prices are valid as of September 1, 2024 for Saint Petersburg and the Leningrad Oblast
Prerequisites for building a house:
(compliance is monitored by the customer independently and is not included in the price)
(compliance is monitored by the customer independently and is not included in the price)
- Utility system available on the site, connected to the construction site: electricity, sewage and water supply
- Ready foundation
- Access roads to the construction site corresponding to the dimensions of transport
