Serially-produced frame house total area of 56 m² with an open terrace.
The house is built on a site according to frame technology using pre-prepared elements. The lightweight structure is erected on any foundation. The house is heat-insulated for living in winter.
The house is built on a site according to frame technology using pre-prepared elements. The lightweight structure is erected on any foundation. The house is heat-insulated for living in winter.
The space of the house is used with maximum efficiency — it contains exactly as much space as is necessary for a comfortable stay.
With a small internal area, the house contains two bedrooms with built-in wardrobes, a bathroom with a bath, a spacious entrance hall and a kitchen-living room.
The terrace can have any shape and size.
With a small internal area, the house contains two bedrooms with built-in wardrobes, a bathroom with a bath, a spacious entrance hall and a kitchen-living room.
The terrace can have any shape and size.
DELO HOUSE 2
PROST
Shelving with five shelves
375 €
Shelving with five shelves
375 €
The project allows two bedrooms to be combined into one and provide more storage space.
The layout can be mirrored in any direction, and the windows can be positioned depending on the cardinal points, the desired view and the access way.
The house has a simple, easy-to-build and reliable structure.
During construction, only high-quality, environmentally friendly materials are used. The house is designed taking into account the standard sizes of materials and almost no wasteleft during its construction. This optimizes its cost and saves natural resources.
The layout can be mirrored in any direction, and the windows can be positioned depending on the cardinal points, the desired view and the access way.
The house has a simple, easy-to-build and reliable structure.
During construction, only high-quality, environmentally friendly materials are used. The house is designed taking into account the standard sizes of materials and almost no wasteleft during its construction. This optimizes its cost and saves natural resources.
24.25 m²
3.45 m²
8.60 m²
8.60 m²
6.85 m²
4.45 m²
10.5 m²
56.2 m²
80.6 m²
13 м х 6.2 м х 4.4 m
3.45 m²
8.60 m²
8.60 m²
6.85 m²
4.45 m²
10.5 m²
56.2 m²
80.6 m²
13 м х 6.2 м х 4.4 m
1. Kitchen-living room
2.Bathroom
3. Bedroom
4. Bedroom
5. Hall
6. Entrance hall
7. Terrace
Usable floor area:
Built-up area:
Dimensions (L х W х H):
2.Bathroom
3. Bedroom
4. Bedroom
5. Hall
6. Entrance hall
7. Terrace
Usable floor area:
Built-up area:
Dimensions (L х W х H):
1
2
3
4
5
6
7
6.2 m
13 m
4.4 m
2.85 m
0
DELO HOUSE 2
Frame house total area of 56 m² with an open terrace.
The house is built on a site according to frame technology using pre-prepared elements. The lightweight structure is erected on any foundation. The house is heat-insulated for living in winter.
The house is built on a site according to frame technology using pre-prepared elements. The lightweight structure is erected on any foundation. The house is heat-insulated for living in winter.
The space of the house is used with maximum efficiency — it contains exactly as much space as is necessary for a comfortable stay.
With a small internal area, the house contains two bedrooms with built-in wardrobes, a bathroom with a bath, a spacious entrance hall and a kitchen-living room.
The terrace can have any shape and size.
With a small internal area, the house contains two bedrooms with built-in wardrobes, a bathroom with a bath, a spacious entrance hall and a kitchen-living room.
The terrace can have any shape and size.
The project allows two bedrooms to be combined into one and provide more storage space.
The layout can be mirrored in any direction, and the windows can be positioned depending on the cardinal points, the desired view and the access way.
The house has a simple, easy-to-build and reliable structure.
During construction, only high-quality, environmentally friendly materials are used. The house is designed taking into account the standard sizes of materials and almost no wasteleft during its construction. This optimizes its cost and saves natural resources.
The layout can be mirrored in any direction, and the windows can be positioned depending on the cardinal points, the desired view and the access way.
The house has a simple, easy-to-build and reliable structure.
During construction, only high-quality, environmentally friendly materials are used. The house is designed taking into account the standard sizes of materials and almost no wasteleft during its construction. This optimizes its cost and saves natural resources.
1. Kitchen-living room: 24.25 m²
2. Bathroom: 8.60 m²
3. Bedroom: 8.60 m²
4. Bedroom: 8.60 m²
5. Hall: 6.85 m²
6. Entrance hall: 4.45 m²
7. Terrace: 10.5 m²
Usable floor area: 56.2 m²
Built-up area: 80.6 m²
Dimensions (L х W х H): 13 м х 6.2 м х 4.4 m
2. Bathroom: 8.60 m²
3. Bedroom: 8.60 m²
4. Bedroom: 8.60 m²
5. Hall: 6.85 m²
6. Entrance hall: 4.45 m²
7. Terrace: 10.5 m²
Usable floor area: 56.2 m²
Built-up area: 80.6 m²
Dimensions (L х W х H): 13 м х 6.2 м х 4.4 m
House price
House with finishing |
Built-up area | 80.6 m² | |
| Usable floor area | 56.2 m² | ||
| Dimensions (LхWхH) | 13 m х 6.2 m х 4.4 m | ||
Frame |
External walls, partitions | Planed kiln-dried board 196х46 mm | ≈ 10 mln ₽ |
| Floor beams | Planed kiln-dried board 196х46 mm | ||
| Rafters | Planed kiln-dried board 196х46 mm | ||
| Heat insulation | Rockwool Light Batts stone wool (or analogue from other manufacturers) walls -200 mm, ceiling - 200 mm; MDVP Beltermo 35 mm |
||
| Noise insulation of interior walls | Rockwool Light Batts stone wool 100 mm, plywood 10+10 mm | ||
| Wind and vapor barrier | Delta-Dawi GP film, MDM Ventia Bronze membrane, Delta Multi-Band M60 tape, MDVP Beltermo 35 mm |
||
Outside finishing |
Roof | Profiled flooring MP-18 0.5 mm, corner elements, drain | |
| Walls | MDVP 35 mm, cedar planken, antiseptic oil, stainless steel fasteners | ||
| Entrance door | Thermal insulated door Alutech Аlt W72 | ||
Interior finishing |
Walls and ceiling | Cedar planken, oil/paint, gypsum board, ceramic granite | |
| Floor | Engineering oak board | ||
| Bathroom walls | Moisture resistant gypsum board 12.5 mm, tiles | ||
| Bathroom floor | Tiles | ||
| Doors | Сoncealed doors | ||
Glass fixing |
Facade windows | Energy-saving double-glazedwindows with thermal break | |
Lighting |
Interior lighting | Surface mounted LED luminaires | |
Utility system |
Water supply and sewage | Water heater Electrolux EWH 80 Formax DL, heating cable, hidden piping (polypropylene / metal- plastic), water supply, sewage pipes | |
| Electrical | Concealed wiring, built-in electrical panel, switches | ||
| Ventilation | Intellegent ventilation system Healthbox 3.0 | ||
| Heating | Water underfloor heating (polyethylene pipe with increased temperature resistance) / convector | ||
Production time |
3,5 months |
Prices are valid as of September 1, 2023 for Saint Petersburg and the Leningrad Oblast
The price does NOT include:
Furniture and plumbing |
Kitchen and wardrobe | Chipboard Egger | ≈ 2 mln ₽ |
| Refrigerator | |||
| Washer | |||
| Tap | |||
| Stove | |||
| Lavatory basin | |||
| Sink | |||
| Shower | |||
| Washing machine | |||
| Sofa | Delo | ||
| Tables | Delo, Kroogster and Yo models | ||
| Chairs | Delo, Tu and Yo models | ||
| Bed | Solid pine, water-based varnish | ||
| Matress | 160х200 cm | ||
| Blanket | 200х200 cm | ||
| Pillows | 50x70 cm | ||
| Linens | Delo Design | ||
| Tablware | Delo | ||
Foundation |
Concrete slab / concrete piles (the cost of the foundation depends on the location, the type of soil, the length of the piles, the need to remove stones, etc. It is recommended to take a soil sample and conduct inspection |
from 400 000 ₽ | |
Wastewater treatment station |
Zorde-4 (for 2-5 people) |
Erection: excavation, digging, submersion of the station, backfilling of the central heating station (ratio of cement to sand 1/4, 1/3) connection of electrics, (100 km from the pumping equipment, city) welding of branch piping, inspection and laying of pipes up to 10m, lead -into the house | ≈ 125 000 ₽ (in 100 km from the city) |
| Kolo Vesi premium station | Kolo Vesi 3 (for 2 people) | ≈ 155 000 ₽ | |
| Kolo Vesi 5 (for 4-5 people) | ≈ 180 000 ₽ | ||
Wood burning fireplace |
from 100 000 ₽ | ||
Prices are valid as of September 1, 2023 for Saint Petersburg and the Leningrad Oblast
Prerequisites for building a house:
(compliance is monitored by the customer independently and is not included in the price)
(compliance is monitored by the customer independently and is not included in the price)
- Utility system available on the site, connected to the construction site: electricity, sewage and water supply
- Ready foundation
- Access roads to the construction site corresponding to the dimensions of transport
