Modular house total area of 69 m² with open terrace.
The house consists of prefabricated modules assembled right on the site. The lightweight structure is erected on any foundation. The house is heat-insulated for living in winter
The house consists of prefabricated modules assembled right on the site. The lightweight structure is erected on any foundation. The house is heat-insulated for living in winter
The space of the house is used with maximum efficiency — it contains exactly as much space as necessary for a comfortable stay.
With a small internal area, the house contains two bedrooms with built-in wardrobes,
a bathroom with a bath, a spacious entrance hall and a kitchen-living room.
The terrace can have any shape and size.
With a small internal area, the house contains two bedrooms with built-in wardrobes,
a bathroom with a bath, a spacious entrance hall and a kitchen-living room.
The terrace can have any shape and size.
MODULAR HOUSE
PROST
Shelving with five shelves
375 €
Shelving with five shelves
375 €
The project allows two bedrooms to be combined into one and provide more storage space.
The layout can be mirrored in any direction, and the windows can be positioned depending on the cardinal points, the desired view and the access way.
The layout can be mirrored in any direction, and the windows can be positioned depending on the cardinal points, the desired view and the access way.
Module frame is made from CNC-cut LVL beam. It guarantees high precision of module dimensions and additional rigidity during the transportation and installation.
Only high-quality, environmentally friendly materials are used during construction. The house is designed taking into account the standard sizes of materials so almost no waste has left. This saves natural resources.
Only high-quality, environmentally friendly materials are used during construction. The house is designed taking into account the standard sizes of materials so almost no waste has left. This saves natural resources.
1. Kitchen-living room
2. Bathroom
3. Bedroom
4. Bedroom
5. Entrance hall
6. Hall
7. Terrace
Usable floor are:
Built-up area
Dimensions (L х W х H):
2. Bathroom
3. Bedroom
4. Bedroom
5. Entrance hall
6. Hall
7. Terrace
Usable floor are:
Built-up area
Dimensions (L х W х H):
35.7 m²
4.2 m²
9 m²
9 m²
4.4 m²
6.6 m²
11.3 m²
69 m²
93.3 m²
13.3 m х 7.8 m х 2.7 m
4.2 m²
9 m²
9 m²
4.4 m²
6.6 m²
11.3 m²
69 m²
93.3 m²
13.3 m х 7.8 m х 2.7 m
0.0 m
2.7 m
13.3 m
7.8 m
2.7 m
0.0 m
1
4
2
3
5
6
7
MODULAR HOUSE
Modular house total area of 69 m² with open terrace.
The house consists of prefabricated modules assembled right on the site. The lightweight structure is erected on any foundation. The house is heat-insulated for living in winter
The house consists of prefabricated modules assembled right on the site. The lightweight structure is erected on any foundation. The house is heat-insulated for living in winter
The project allows two bedrooms to be combined into one and provide more storage space.
The layout can be mirrored in any direction, and the windows can be positioned depending on the cardinal points, the desired view and the access way.
The layout can be mirrored in any direction, and the windows can be positioned depending on the cardinal points, the desired view and the access way.
1. Kitchen-living room: 35.7 m²
2. Bathroom: 4.2 m²
3. Bedroom: 9 m²
4. Bedroom: 9 m²
5. Entrance hall: 4.4 m²
6. Hall: 6.6 m²
7. Terrace: 11.3 m²
Usable floor are: 69 m²
Built-up area: 93.3 m²
Dimensions (L х W х H): 13.3 m х 7.8 m х 2.7 m
The space of the house is used with maximum efficiency — it contains exactly as much space as necessary for a comfortable stay.
With a small internal area, the house contains two bedrooms with built-in wardrobes, a bathroom with a bath, a spacious entrance hall and a kitchen-living room.
The terrace can have any shape and size.
2. Bathroom: 4.2 m²
3. Bedroom: 9 m²
4. Bedroom: 9 m²
5. Entrance hall: 4.4 m²
6. Hall: 6.6 m²
7. Terrace: 11.3 m²
Usable floor are: 69 m²
Built-up area: 93.3 m²
Dimensions (L х W х H): 13.3 m х 7.8 m х 2.7 m
The space of the house is used with maximum efficiency — it contains exactly as much space as necessary for a comfortable stay.
With a small internal area, the house contains two bedrooms with built-in wardrobes, a bathroom with a bath, a spacious entrance hall and a kitchen-living room.
The terrace can have any shape and size.
Module frame is made from CNC-cut LVL beam. It guarantees high precision of module dimensions and additional rigidity during the transportation and installation.
Only high-quality, environmentally friendly materials are used during construction. The house is designed taking into account the standard sizes of materials so almost no waste has left. This saves natural resources.
Only high-quality, environmentally friendly materials are used during construction. The house is designed taking into account the standard sizes of materials so almost no waste has left. This saves natural resources.
House price
House with finishing |
Built-up area | 93.3 m² | |
| Usable floor area | 68.9 m² | ||
| Dimensions (LхWхH) | 13.3 m х 7.8 m х 2.7 m | ||
Frame |
External walls, partitions | LVL-beam 145х30 mm / 90х30 mm | 196 500 € |
| Floor beams | LVL-beam 190х30 mm | ||
| Rafters | LVL-beam 190х30 mm | ||
| Heat insulation | TeploKnauf mineral wool (or analogue from other manufacturers) Floor - 200 mm, walls - 150 mm, ceiling - 200 mm |
||
| Noise insulation of interior walls | TeploKnauf mineral wool (or analogue from other manufacturers) | ||
Outside finishing |
Roof | Profiled flooring MP-18 0.5 mm, corner elements, drain | |
| Walls | MDVP, softwood planken, oil | ||
| Entrance door | Warm metal or wooden door with thermal break | ||
Interior finishing |
Walls and ceiling | Birch plywood, matt varnish | |
| Floor | Oak two-layer parquet board | ||
| Bathroom walls | Birch plywood, matt varnish / birch plywood, tiles | ||
| Bathroom floor | Tiles | ||
| Doors | Birch plywood | ||
Glass fixing |
Facade windows | Double-glazed windows | |
Lighting |
Interior lighting | Surface mounted LED luminaires | |
Utility system |
Water supply and sewage | Hidden piping (polypropylene), sewage pipes | |
| Electrical | Concealed wiring, smart home system | ||
| Ventilation | Air supply valves(Tion), air removal by humidity and CO2 sensors | ||
| Heating | Electric underfloor heating, electric convector, heating cable over the perimeter | ||
Furniture and plumbing |
Kitchen and wardrobe | Chipboard Egger | ≈ 36 000 € |
| Refrigerator | |||
| Washer | |||
| Tap | |||
| Stove | |||
| Lavatory basin | |||
| Sink | |||
| Shower | |||
| Washing machine | |||
| Sofa | Delo | ||
| Tables | Delo, Kroogster and Yo models | ||
| Chairs | Delo, Tu and Yo models | ||
| Bed | Solid pine, water-based varnish | ||
| Matress | 160х200 cm | ||
| Blanket | 200х200 cm | ||
| Pillows | 50x70 cm | ||
| Linens | Delo | ||
| Tableware | Delo | ||
Total cost |
≈ 232 500 € |
Manufacturing time |
4 months |
||
Assembling |
- modules getting fixed to each other and to the foundation - joint sealing - setting uo utilities - outside finishing - inside finishing |
1-3 days |
|
The price does NOT include:
| St.Petersburg | |||
Delivery |
Modules are trasported to the location (If it’s impossible for trawl to reach the location, modules are loaded on to more mobile vehicles and transported to the site) |
||
Unloading |
Modules are placed on foundation with a crane (a crane must be able to install 4 ton modules from the crane's installation point to the farthest point of the foundation.) |
||
Foundation |
The cost of the foundation depends on the location, the type of soil, the length of the piles, the need to remove stones, etc. It is recommended to take a soil sample and conduct inspection | ||
| Recommended foundation: concrete slab / concrete piles | from 4 500 € | ||
| Screw piles | from 2 500 € | ||
Wastewater treatment station |
Zorde-4 (for 2-5 people) |
Erection: excavation, digging, submersion of the station, backfilling of the central heating station (ratio of cement to sand 1/4, 1/3) connection of electrics, (100 km from the pumping equipment, city) welding of branch piping, inspection and laying of pipes up to 10m, lead -into the house | ≈ 1 500 € (in 100 km from the city) |
| Kolo Vesi premium station | Kolo Vesi 3 (for 2 people) | ≈ 1 500 € | |
| Kolo Vesi 5 (for 4-5 people) | ≈ 2 250 € | ||
Terrace |
20 m2, 28 mm larch decking, piled metal foundation | 1 500 € (in 60 km from the city) |
|
Wood burning fireplace |
from 1 250 € | ||
Prices are valid as of March 1, 2021
Prerequisites for building a house:
(compliance is monitored by the customer independently and is not included in the price)
(compliance is monitored by the customer independently and is not included in the price)
- Utility system available on the site, connected to the construction site: electricity, sewage
and water supply - Ready foundation
- Access roads to the construction site corresponding to the dimensions of transport
